FLAP DISCS

HIGH-PERFORMANCE ABRASIVES

Flap or lamellar grinding discs

Flap discs or lamellar grinding discs, also known as flap wheels, are primarily used for grinding, deburring, rust removal, and polishing metal, wood, and plastic surfaces. They are particularly well-suited for hard-to-reach areas and contouring. Compared to grinding discs, flap discs have a lower material removal rate but are gentler on the material and produce less vibration.

Flap disc LSG-Z profi-line

Specification

Flap disc, straight design with a fiberglass backing that leaves no scratches on the workpiece. Zirconia coating, soft and cool grinding disc in standard design.

Applications

Stainless steel, metalworking, steel.

Dimensions/mm

Grain sizes

Z40, 60, 80

Z40, 60, 80, 120

Z40, 60

RPM

13.200

12.200

8.600

Flap disc LSGS-Z profi-line

Specification

Angled flap disc with a fiberglass backing that leaves no scratches on the workpiece. Zirconia coating, soft and cool grinding disc in standard design.

Applications

Stainless steel, metalworking, steel.

Dimensions/mm

Grain sizes

Z40, 60, 80

Z40, 60, 80, 120

Z40, 60

RPM

13.200

12.200

8.600

Flap disc LSG-K

Specification

Straight flap disc with a fiberglass backing and highly effective ceramic grain. The ceramic grain resharpens itself continuously, resulting in exceptional grinding performance. Our premium product, with its particularly high material removal rate, impresses with minimal clogging and a cool grinding action.

Applications

Extremely hard surfaces, such as high-alloy steels, chromium and chromium-nickel compounds, nickel and titanium alloys.

Dimensions/mm

Grain sizes

K40

RPM

12.200

Flap disc LSGS-K

Specification

Straight flap disc with a fiberglass backing and highly effective ceramic grain. The ceramic grain resharpens itself continuously, resulting in exceptional grinding performance. Our premium product, with its particularly high material removal rate, impresses with minimal clogging and a cool grinding action.

Applications

Extremely hard surfaces, such as high-alloy steels, chromium and chromium-nickel compounds, nickel and titanium alloys.

Dimensions/mm

Grain sizes

K40

RPM

12.200

Flap discs LSGV-A (made of abrasive fleece)

Specification

Flap discs with highly effective abrasive fleece for surface finishing such as preparing and polishing welds, descaling, rust removal, cleaning, removing paint residues, preparing surfaces for painting, and polishing stainless steel.

Applications

Stainless steel, steel, aluminum, non-ferrous metals.

Dimensions/mm

Structure

C = coarse (brown)

M = medium (red)

F = fine (blue)

RPM

13.200 / 80 m/s

12.200 / 80 m/s

PICTOGRAMS

WEFRA QUALITY LINES

To achieve maximum efficiency, the product should be tailored to your requirements and the grinding process. Therefore, the grinding tool's performance must be selected based on the desired end result. That's why we offer various quality levels with different performance classes. Our eco-line represents the most cost-effective solution for grinding small batches. The profi-line is our all-round specification with an excellent price-performance ratio. The premium-line defines our high-end products, offering the best performance and longest service life.

eco-line

profi-line

premium-line
